Platform Serrated Galvanized Steel Bar Grating 600mm Width

Name: Platform Serrated Galvanized Steel Bar Grating 600mm Width
Brand: NOVA
SKU: NOVA
Price: 50 USD
Availability: InStock
Rating: 4.8 (132 reviews)

Large Image : Platform Serrated Galvanized Steel Bar Grating 600mm Width

Product Details:

Place of Origin:	CHINA
Brand Name:	NOVA

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece
Price:	50 - 99 Pieces $50.00 100 - 199 Pieces $46.00 200 - 499 Pieces $45.00 >=500 Pieces $43.00
Packaging Details:	1. Strap Packaging. 2. Pallet Packaging. 3. Screw Rod Fixation. 4. Other pacakge is available.
Delivery Time:	Quantity(Tons) 1 - 1200 >1200 Est. Time(days) 30 To be negotiated
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	5000 Piece/Pieces per Month

Contact Now

Detailed Product Description

Material:	Lower Carbon Steel	Steel Grating Size:	3'x20', 3'x24', 3'x30'
Steel Bearing:	30,40,60,100mm	Surface Treatment:	Mild, Galvanized,power Coating
Application:	Trench Drains,Driveway Road,Garage Trench Drain	Specification:	19-w-4, 15-w-2, 30/100, 40/50
Bearing Bar:	25*3mm	Pitch Of Cross Bar:	30, 38, 50, 76, 100mm Etc. With 50, 100mm Recommended.
Cross Bar Size:	Twisted Bar 55/66/8*8mm	Width:	600-1250mm
High Light:	serrated galvanized steel bar grating , platform galvanized steel bar grating , 600mm width galvanized steel bar grating

Galvanized Platform Serrated Steel Grating/drainage steel grating shower drain grates trench drain cover

1. Material: low carbon steel, stainless steel, aluminum alloy, etc.

2. Cross bar material: Q235A / stainless steel 304 twisted bar, round bar, square bar, etc.

3. Flat bar specification:

1> Plain flat bar:

Thickness: 3mm, 5mm.

Height: 25mm, 30mm, 32mm, 40mm, 45mm, 50mm, 60mm, etc.

2> I-shaped flat bar:

Thickness of both ends: 5mm.

Thickness of the center: 3mm.

Height: 25mm, 32mm, 38mm, 44mm, 50mm, etc.

Bearing Bar Width: 25mm, 30mm, 32mm, 40mm, 60mm, 80mm, etc

Bearing Bar Thickness: 2.5mm, 3mm, 4mm, 5mm, etc

Bearing Bar Pitch: 30mm, 40mm, 50mm, etc

Cross Bar Diameter: 5mm, 6mm, 8mm, etc.

Platform Serrated Galvanized Steel Bar Grating 600mm Width 0

Standards Of Galvanized Overcher Steel Grating.

	Steel grating standard	Steel standard	Galvanizing standard
China	YB/T 4001.1-2007	GB700-88	GB/T13912-2002
USA	ANSI/NAAMM(MBG531)	ASTM(A36)	ASTM(A123)
U.K.	BS4592	BS4360(43A)	BS729
Australia	AS1657	AS3679	AS1650

Platform Serrated Galvanized Steel Bar Grating 600mm Width 1

Advantages:

High strength and light structure

Powerful anti-corrosion, durable and long working life

Beautiful appearance, bright surface

No dirt-rain-snow deposit, automatic cleaning, easy maintenance

Good ventilation,day-lighting,heat-dispersing,resistant to sliding and explosion.

Easy installation and disassembly

Platform Serrated Galvanized Steel Bar Grating 600mm Width 2

Application of drainage trench cover steel grating

Steel grating is mainly used in the chemical industry, food processing, catwalk and trench cover and other industrial as listed: Power plant, Chemical plant, Oil refinery, Steel plant, Machinery plant, Paper-making factory, Waste water treatment, Pharmacy industrial, Food processing,etc.

Platform Serrated Galvanized Steel Bar Grating 600mm Width 3

steel grating packaging:

1. Steel pallets, then plastic film in the surface.
2. Stow wood, or wooden tray with steel strip.

3. Steel frame fixing.

Transport in iron box.

According to your packing requirements.

steel grating has been used in hundreds of industrial fields

			boiler platform

			platform bridge

			refined oil refinery

			power station

			the factory floor

			huhsbandry

			municipal engineering

			building materials industry

			factory corridor

			bridge corridor

			offshore engineering

			building industry

			steel manufacture

			oceangoing vessel

			sewage treatment

			warehouse shelf
