|500m south of Cuianpu village, Anping, Hengshui, Hebei, China|
Payment & Shipping Terms:
|Material:||Galvanized Steel Wire,pvc Coated Wire||Surface:||PVC Coated,zinc Coated|
|Wire Diameter:||2.0-4.0mm||Hole Size:||60*80mm,80*100mm|
|Feature:||Low Cost And Easy To Transport||Packing:||Pallet|
gabions and reno mattresses,
landscape rock cages
Welded mesh gabion reno mattress / heavy zinc coated river mattress
Mattresses are relatively small in height in relation to the lateral dimension of a gabion and are generally used for channel linings. welded mesh mattresses are manufactured from welded wire mesh and assembled with our preformed spiral binder. We suggest the use of preformed stiffeners at each exposed face of the gabion.
Gabion mattresses material:
1.Zinc 5% Aluminum - mixed rare earth alloy steel.
2.Zinc 5% Aluminum - mixed rare earth alloy steel wire PVC coated.
3.Hot dipped high galvanized steel wire.
4.PVC coated hot-dip high galvanized steel wire.
Sizes of River mattress/reno mattress:
|Length (m)||Width (m)||Height (m)||Mesh Type (cm)|
|3||2||0.17 - 0.23 - 0.30||5x5|
|4||2||0.17 - 0.23 - 0.30||5x5|
|5||2||0.17 - 0.23 - 0.30||5x5|
|6||2||0.17 - 0.23 - 0.30||5x5|
Features of welded reno mattress
1.Flexibility: low-carbon steel wire as a combination of structure, Reno mattress has a strong flexibility to adapt to the local subsidence deformation of foundation and protected body. Reno mattresses can adjust their own healing, to prevent the continued development of the deformation.
2.Durability: The Reno mattress is a structure made of hexagonal woven Low carbon steel wire, with hard rock combined to form a very large overall durability.
3.Environmental friendly: Reno mattresses are filled with stones Meeting certain requirements to form protection structures. In the waterfront environment, the voids in the rock fill become progressively filled with silt, promoting vegetation growth which is essential to the preservation and maintenance of the ecological balance of the surrounding environment.
4.Permeability: The stone fill allows the water to seep through the structure while retaining the soil, therefore no additional drainage is required to relieve the hydrostatic pressures. The Reno mattress ensure natural water exchange with the natural groundwater, further strengthened the environmental effects.
5.Integrity: The Reno mattress constituted by independent units, but between each adjacent unit has steel wire twisted, So it has good integrity.
6.Economy: The stones Reno mattress required is gravel or pebbles, so the stones cost is low. Reno mattress construction does not require skilled labor because they are very easy to build. No drainage system, Limited construction equipment can be used. If the design and construction is reasonable, the structure is long life and no maintenance.
Welded reno mattress. The main application of welded reno mattress is for decoration, such as landscape construction, fire place and planters applications. It can be used for slope protection as the woven reno mattress.
When requesting a quote, please specify:
size of units (LxWxH)
type of mesh size (60*80,80*100mm)
type of coating (galvanized wire, galfan wire,pvc coated wire)
Contact Person: Glory
