|Wire Diameter:||2.0-4.0mm||Mesh Size:||60*80,80*100,100*120,120*150mm Etc|
|Hole Shape:||Hexagonal||Surface Treatment:||Zinc Coated,PVC Coated|
|Type:||Woven Mesh||Material:||Galvanized Wire,pvc Coated Wire|
|Name:||Double-Twisted Hexagonal Gabion Mesh PVC Coated Wire Stone Gabion Cages|
welded gabion box,
garden wall wire baskets
Hot Dip Galvanized Hexagonal Wire Mesh Gabion Boxes For Soil Erosion Preventing
Hexagonal Wire Mesh gabion box is the most common and most practical kind used in the project.To fill with stones at the river bank or seaside to stop flood, on the mountain to prevent rock falling.
It's made of hot-dip galvanizing or galfan wire, If need, 0.5 mm thick PVC can be coated on the galvanized/galfan wire to provide added protection for use in aggressive environments with acidic soils and water, in salt or fresh water or wherever the risk of corrosion is present.In order to reinforce the structure, the edge wire has a greater diameter than the mesh wire.The gabion box is divided into units by means of diaphragms positioned at approximately 1m centres.
Gabion wire mesh boxes/mattress specifications
|Length (m)||width (m)||height (m)||diaphragm||volume||tolerance|
1.Stone filling is characterized by porosity that enables water to flow and doesn’t create hydraulic pressure on the panels of gabion structures, it has drainage function.
2.Gabions are able to deform while still retaining their integrity, they adapt themselves to terrain where the concrete structures may crack and fail, they are suitable for unstable subgrades.
3.The high resistance and durability is secured by outstanding features of steel wire, its surface treatment by heavy galvanization or PVC coating and by the quality of stone filling. During the lifetime the pores are filled up with alluvia and the whole structure is grown through by vegetation what increases its strength and therefore is able to resist against great pressures.
4.Gabion baskets are made from double twisted, hexagonal woven wire mesh. The wire used to manufacture the gabion baskets is fabricated from high quality tensile, heavily galvanized steel, which is also available with an extruded PVC coating for additional corrosion protection, when required by the application. The double twist of the woven wire mesh provides integrity, strength and continuity to the structure by adding a non-raveling effect that prevents any accidental damage from spreading.
Gabion stone box applications:
Building blocks of gravity walls
Forming of gravity walls
Reinforced structure (a combination of reinforcing wire mesh containers)
Control and guide of water or flood
Flood bank or guiding bank
Preventing of rock breaking
Water and soil protection
Strengthening structure of soil
Protection engineering of seaside area.
