Double Twisted Hexagonal Steel Wire PVC Coated Mesh Gabion Stone Cage

Double Twisted Hexagonal Steel Wire PVC Coated Mesh Gabion Stone Cage
Double Twisted Hexagonal Steel Wire PVC Coated Mesh Gabion Stone Cage Double Twisted Hexagonal Steel Wire PVC Coated Mesh Gabion Stone Cage

Large Image :  Double Twisted Hexagonal Steel Wire PVC Coated Mesh Gabion Stone Cage

Product Details:
Place of Origin: China
Brand Name: Nova
Certification: ISO9001
Model Number: Nova-211
Payment & Shipping Terms:
Minimum Order Quantity: 200 sets
Price: Negotiable
Packaging Details: Covered with plastic and the put on wooden pallet
Delivery Time: 5-10 days, according to buyer's requirement
Payment Terms: T/T, Western Union
Supply Ability: 10000 sets per week
Detailed Product Description
Wire Diameter: 2.0-5.0mm Hole Size: 60*80,80*100,100*120 Etc
Surface Treatment: Pvc Coated Material: Steel Wire,iron Wire Etc
Hole Shape: Hexagonal Color: Grey,green,black Etc
Type: Double Twist Name: Double Twisted Hexagonal Steel Wire PVC Coated Mesh Gabions
Highlight:

plastic coated wire mesh baskets

,

pvc coated galvanized wire mesh

Double Twisted Hexagonal Steel Wire PVC Coated Mesh Gabion Stone Cage



Product Description:



Double Twisted Hexagonal Steel Wire PVC Coated Mesh Gabions. Gabions shall be fabricated in such a manner that the sides, ends, lid and diaphragms can be assembled at the construction site into rectangular baskets of the sizes specified and shown in the drawings. Gabions shall be of single unit construction: the base, lid, ends and sides shall be either woven into a single unit or edge of these members connected to the base section of the gabion in such a manner that strength and flexibility at the connecting point does not compromise the engineered structural design of the gabion. Where the length of the gabion exceeds one and one half its horizontal width, the gabion shall be divided by diaphragms of the same mesh and gauge as the body of the gabion, into cells whose length does not exceed the horizontal width. The gabion shall be furnished with the necessary diaphragms secured in proper position on the base in such a manner that no additional tying is required at this juncture.



The protective coating must be resistant to the destructive effects of immersion in acidic, salt, or polluted water, exposure to ultraviolet light and abrasion and shall retain these characteristics after a period of not less than 3000 hours under tests in accordance with ASTM G-23, All wire used in the fabrication of gabion mattresses and in the wiring operations shall conform to ASTM A-974-97



Hexagonal Wire Netting Gabions
Opening
(mm)
Wire Diameter(Metal Wire)
(mm)
Wire Diameter (PVC Coate)/
Inner/Outside(mm)
Strands
60X80 f2.0-2.8 f2.0/3.0-2.5/3.5 3
80X100 f2.0-3.2 f2.0/3.0-2.8/3.8 3
80X120 f2.0-3.2 f2.0/3.0-2.8/3.8 3
100X120 f2.0-3.4 f2.0/3.0-2.8/3.8 3
100X150 f2.0-3.4 f2.0/3.0-2.8/3.8 3
120X150 f2.0-4.0 f2.0/3.0-3.0/4.0 3



Gabion Basket
A twisted hexagonal mesh container of variable sizes, uniformly partitioned into internal cells, filled with stone at the project toform flexible, permeable, monolithic structures such as retaining walls, sea wall, channel linings, revetments, and weirs for erosion control projects.



Gabion Mattress
Double Twisted wire mesh container uniformly partitioned into internal cells with relatively small height inrelation to other dimensions, having smaller mesh openings than the mesh used for gabion basket, gabion mattresses are generally used for riverbank protection and channel linings.



PVC Coated Gabion applications:



PVC coated steel double twisted hexagonal wire mesh baskets filled with stone used for various applications including but not limited to retaining walls, mechanically stabilized soil retaining structures, stream and river bank protection, slope paving, outfall structures, weirs and drop structures etc.



Features of PVC coated gabions:



Corrosion and rust resistance.
Acid and alkali resistance.
Low cost and economical.
Maintenance free.
Easy to install and assemble.
Blend with surrounding environments.



Double Twisted Hexagonal Steel Wire PVC Coated Mesh Gabion Stone Cage 0
