Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh

Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh
Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh

Large Image :  Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh

Product Details:
Place of Origin: CHINA
Brand Name: NOVA
Payment & Shipping Terms:
Minimum Order Quantity: 5m2 size
Price: 1-100US$/m2
Packaging Details: Hot sale 200x40 mesh stainless steel 316 316L Reverse Dutch Weave Wire Mesh Belt For Plastic Extrusion (1)paper tube support inside , and waterproof paper , and wooden box outside . (2)special package can be customized as per customers' request
Delivery Time: Quantity(Square Meters) 1 - 200 >200 Est. Time(days) 2 To be negotiated
Payment Terms: L/C,T/T,Western Union
Supply Ability: 500 Square Meter/Square Meters per Day

Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh

Description
Material: Stainless Steel Width: Usually 127mm, Or Customized
Wire Diameter: 0.02mm-0.5mm Feature: High Strength,corrosion Resistant,heat Resistant
Shape: In Roll Package: Plywood Case
Application: Filtering Of Plastic Wire Drawing Bench Weave Style: Dutch Weave
Sample: Free Certificated: ISO-9001:2008
Highlight:

Dutch Weave Stainless Steel Wire Mesh

,

200x40 Dutch Weave Wire Mesh

,

Reverse Dutch Weave Wire Mesh

Reverse Dutch Weave Stainless Steel Wire Mesh Belt - 200x40 Mesh Stainless Steel 316/316L
Also known as contrast type net or contrast seat mesh belt (Dutch cloth), our high-quality reverse dutch weave stainless steel wire mesh offers superior performance for demanding industrial applications.
Key Features
  • Material: Premium stainless steel wire (316/316L)
  • Weaving: Reverse dutch weave pattern
  • Smooth surface with high hardness and continuous mesh structure
  • Excellent dimensional stability with no deformation
  • High temperature and corrosion resistance
  • Flexible mesh with superior filtration performance
  • Precise filtration with high load strength
  • Performs well in both high and low temperature environments
Standard Specifications
Standard length: 10 meters
Width range: 40mm-210mm (maximum width up to 50cm)
Mesh count range: 40 mesh - 350 mesh
Custom sizes: Available upon request
Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh 0
Reverse Dutch Mesh Technical Specifications
Mesh Count Wire Diameter (mm) Thickness (mm) Width (mm)
54*15 0.45*0.6 1.75 50-800
72*15 0.45*0.55 1.7 50-800
132*17 0.23*0.45 1.2 50-1000
160*18 0.28*0.45 1.27 50-1000
200*40 0.17*0.27 0.7 50-1500
260*40 0.15*0.27 0.65 50-1500
300*40 0.13*0.27 0.65 50-1500
350*40 0.13*0.27 0.6 50-1500
Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh 1
Industrial Applications
Our reverse dutch weave stainless steel mesh is widely used in various industries including:
  • Plastic processing (woven bags, plastic film)
  • Aerospace and transportation
  • Petroleum and chemical processing
  • Chemical fiber production
  • Machinery and plastic products manufacturing
  • Scientific research applications
  • Automatic belt filters for plastic extruders
  • Plastic melt filtration systems
Our products are exported worldwide to countries including the UK, Germany, Japan, USA, South Africa, Indonesia, Thailand, and other Southeast Asian regions.
Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh 2
Packaging Options
Standard packaging includes waterproof paper inside and plywood case outside.
Custom packaging solutions available to meet your specific requirements.
Stainless Steel 316 Reverse Dutch Weave Wire Mesh 200x40 Mesh 3
