Product Description:
The Gabion Basket Mesh is made of high-quality galvanized steel wire, which has a tensile strength of 380-550N/mm2. The surface treatment includes galvanizing and PVC coating, which provides excellent resistance to corrosion and rust.
The Gabion Wall Mesh has a variety of applications, including control and guidance of water or floods, flood bank or guide bank, preventing rock breaking, water and soil protection, bridge protection, strengthening the structure of the soil, and protection engineering of seaside areas. The hexagonal braided design allows for flexibility and easy installation.
These Gabion Baskets are perfect for soil erosion control and are especially useful in areas where there is a high risk of flooding. They are also commonly used for landscaping purposes, such as creating retaining walls or decorative features.
The Gabion Wall Mesh is a cost-effective solution for many engineering and construction projects. It provides stability and protection to slopes, riverbanks, and other vulnerable areas.
Overall, the Galvanized Hexagonal Braided Gabion Baskets are a reliable and durable option for any water or soil protection project. With their high-quality materials and versatile applications, they are an excellent investment for any construction or engineering project.
| Product Name |
Material |
Mesh Size |
Wire Diameter |
Box Size |
Surface Treatment |
Applications |
| Hexagonal Gabion Mesh |
Galvanized Steel Wire |
100mm x120mm |
2.0mm-4.0mm |
1m x 1m x 1m |
Galvanized / PVC Coated |
Soil erosion control, riverbank protection, landscaping |
| Heavy Duty Gabion Mesh |
Galvanized Steel Wire |
80mm x 100mm |
2.2mm-3.5mm |
2m x 1m x 1m |
Galvanized |
Soil stabilization, rockfall prevention |
| PVC Coated Gabion Mesh |
PVC Coated Wire |
60mm x 80mm |
2.0mm-3.0mm |
3m x 1m x 1m |
PVC Coated |
Aesthetic landscaping, retaining walls |
| Hexagonal Gabion Baskets |
Galvanized Wire |
120mm x150mm |
3.0mm-4.0mm |
2m x 2m x 1m |
Galfan / PVC Coated |
itary protection, flood management |
Features:
- Product Name: Gabion Wire Mesh
- Mesh Size:
- 60x80mm
- 80x100mm
- 80x120mm
- 100x120mm
- 100x150mm
- Surface Treatment:
- Tensile Strength: 380-550N/mm2
- Material: Galvanized Steel Wire
- Product Name: Galvanized Hexagonal Braided Gabion Baskets For Water And Soil Protection, Bridge Protection
- Keywords: Gabion Basket Mesh, Gabion Wall Mesh
Technical Parameters:
Material
The wire material for our product can be selected from galvanized steel wire, stainless steel wire, and PVC-coated steel wire based on the design requirements. The wire diameter usually ranges from 2.0 mm to 5.0 mm depending on the design needs.
Mesh Size
Aperture size, typically selected based on the use requirements, comes in common sizes such as 60 mm x 80 mm, 80 mm x 100 mm, etc.
Dimensions
Our standard box sizes include 1m x 1m x 1m, 2m x 1m x 1m, and 3m x 1m x 1m. If you have special project needs, we can also customize the size of the box.
Structural Strength
Our product boasts strong tensile strength, usually ranging between 350 MPa and 600 MPa, and is highly resistant to corrosion. The galvanization thickness generally ranges from 50 g/m² to 500 g/m², ensuring enhanced durability for the box.
Environmental Adaptability
Our product's lifespan can generally last over 20 years in normal conditions, depending on the materials used and environmental factors.
Installation Requirements
For installation, our product should be installed on a stable foundation. Filling material typically uses cobbles and crushed stones, with a diameter generally between 30 mm and 150 mm.
Applications:
The NOVA Gabion Wire Mesh is suitable for a variety of applications, including the control and guide of water or flood, flood bank or guide bank, preventing rock breaking, water and soil protection, bridge protection, strengthening the structure of soil, and protection engineering of seaside areas. It can be used to create gabion basket mesh, gabion wall mesh, and gabion basket mesh for various purposes.
The product is available in a range of sizes, including box sizes of 1m*1m*2m, 2m*1m*0.5m, 1m*1m*1m, and others. The wire diameter ranges from 2.0mm to 4.0mm, and the mesh size varies from 60x80mm to 100x150mm. The tensile strength of the wire mesh is between 380-550N/mm2.
The NOVA Gabion Wire Mesh is sold in bundles, with a minimum order quantity of 50M2. The price of the product depends on the specifications, and the delivery time is typically 7-10 days. Payment can be made via T/T, L/C, or credit card, and the product is available as required.
Customization:
Brand Name: NOVA
Model Number: NG-1, NG-2
Place of Origin: CHINA
Certification: ECM, SGS, ISO9001
Minimum Order Quantity: 50M2
Price: Depends on specs
Packaging Details: In bundles
Delivery Time: 7-10 days
Payment Terms: T/T, L/C, Credit card
Supply Ability: As required
Zinc Coating: ≥230g/m2
Product name: Galvanized Hexagonal Braided Gabion Baskets For Water And Soil Protection, Bridge Protection
Box Size: 1m*1m*2m, 2m*1m*0.5m, 1m*1m*1m, etc.
Material: Galvanized Steel Wire
Application: Control And Guide Of Water Or Flood, Flood Bank Or Guide Bank, Preventing Of Rock Breaking, Water And Soil Protection, Bridge Protection, Strengthening Structure Of Soil, Protection Engineering Of Seaside Area
Keywords: Gabion Mesh, Gabion Caged Wire Mesh, Gabion Basket Mesh
Support and Services:
Our Gabion Wire Mesh product comes with comprehensive technical support and services to ensure your satisfaction and success. Our team of experts can provide assistance with installation, maintenance, and repair of the product. We also offer customization options to meet your specific needs and requirements.
In addition, we provide training and educational resources to help you maximize the benefits of the Gabion Wire Mesh product. Our team can assist with design and engineering, as well as troubleshooting any issues that may arise.
Our commitment to customer satisfaction means that we are always available to answer your questions and provide support whenever you need it. Contact us today to learn more about our Gabion Wire Mesh technical support and services.
Packing and Shipping:
Product Packaging:
The Gabion Wire Mesh product will be carefully packaged to ensure safe delivery. Each roll of the mesh will be wrapped in plastic to protect it from dust and moisture. The rolls will then be placed in sturdy cardboard boxes and sealed with tape to prevent any damage during shipping.
Shipping:
Shipping will be handled by a reputable courier company. The shipping cost will be calculated based on the weight and destination of the package. Customers can choose their preferred shipping method at checkout. Tracking information will be provided once the package has been dispatched.
FAQ:
Q: What is the brand name of the Gabion Wire Mesh?
A: The brand name of the Gabion Wire Mesh is NOVA.
Q: What are the available models of the Gabion Wire Mesh?
A: The available models of the Gabion Wire Mesh are NG-1 and NG-2.
Q: Where is the Gabion Wire Mesh manufactured?
A: The Gabion Wire Mesh is manufactured in China.
Q: What certifications does the Gabion Wire Mesh have?
A: The Gabion Wire Mesh has ECM, SGS, and ISO9001 certifications.
Q: What is the minimum order quantity for the Gabion Wire Mesh?
A: The minimum order quantity for the Gabion Wire Mesh is 50M2.
Q: What is the price of the Gabion Wire Mesh?
A: The price of the Gabion Wire Mesh depends on the specifications.
Q: How is the Gabion Wire Mesh packaged?
A: The Gabion Wire Mesh is packaged in bundles.
Q: What is the delivery time for the Gabion Wire Mesh?
A: The delivery time for the Gabion Wire Mesh is 7-10 days.
Q: What are the payment terms for the Gabion Wire Mesh?
A: The payment terms for the Gabion Wire Mesh are T/T, L/C, and credit card.
Q: What is the supply ability of the Gabion Wire Mesh?
A: The supply ability of the Gabion Wire Mesh is as required.
