Retaining Wall Hexagonal Gabion Box For Channel Lining And Coastal Protection

Retaining Wall Hexagonal Gabion Box For Channel Lining And Coastal Protection
Retaining Wall Hexagonal Gabion Box For Channel Lining And Coastal Protection Retaining Wall Hexagonal Gabion Box For Channel Lining And Coastal Protection

Large Image :  Retaining Wall Hexagonal Gabion Box For Channel Lining And Coastal Protection

Product Details:
Place of Origin: China
Brand Name: Nova
Certification: ISO9001
Model Number: Nova-089
Payment & Shipping Terms:
Minimum Order Quantity: 3000 square meters
Price: Negotiable
Packaging Details: Covered with plastic, in pallet.
Delivery Time: 5-10 days, according to buyer's requirement
Payment Terms: T/T, Western Union
Supply Ability: 100000 square meters per week
Detailed Product Description
Type: Woven Mesh Material: Galvanized Wire,pvc Coated Wire
Size: 1*1*1,2*1*1m Etc Wire Gauge: 2.0-4.0mm
Sample: Available Aperture: 60*80,80*100,100*120,120*150mm Etc
Hole Shape: Hexagonal Usage: Retaining Wall/river Construction
High Light:

welded gabion box

,

garden wall wire baskets

Galvanized gabion box / gabion box for Channel Lining and Coastal Protection



Product Description:



Different types of gabion box



The gabion box can be divided into galvanized gabion box, PVC coated gabion box, Galfan gabions and 10% aluminum-zinc gabions. They all have excellent corrosion and rust resistance performance, but they are different in the chemical content and performance.



Galvanized gabion. The electric galvanized gabion has no higher than 90 g/m2 zinc coating, which is economical. And the hot dipped galvanized gabion have more than 200 g/m2 zinc coating to be used in the high corrosive applications.



PVC coated gabion. Steel wires or galvanized wire are coated with PVC, which supplies double protection for the gabions in the corrosive environments. The PVC coated gabion can be made into different colors to suit surrounding environments.



Aluminum-zinc gabions. The galvanized wires are added into different content of aluminum to form Galfan gabion and 10% aluminum-zinc gabion. They have triple service life than the galvanized gabions.



Gabion Box Sizes



Length, m



Width, m



Height, m

Number of

Cells, each



Volume, m³

2.0 1.0 1.0 2.0 2.0
3.0 1.0 1.0 3.0 3.0
4.0 1.0 1.0 4.0 4.0
2.0 1.0 0.5 2.0 1.0
3.0 1.0 0.5 3.0 1.5
4.0 1.0 0.5 4.0 2.0
2.0 1.0 0.3 2.0 0.6
3.0 1.0 0.3 3.0 0.9
4.0 1.0 0.3 4.0 1.2



Features of galvanized gabions



Corrosion and rust resistance. Hot dipped galvanized and various other materials can protect gabions from corrosion and rust.


Acid and alkali resistance. Outstanding chemical stability make the gabion to be used in the harsh environments.


High tensile strength. High quality material supplies high tensile strength to defend the high impact from external force.


Wide range of applications. The galvanized gabions can be used in protective and decorative applications in different fields.


Economical. Different materials and structure to satisfy different requirements for the budget and performance.


Ecological. It can maintain the healthily growth of plants and make the gabions be blended with surrounding environments.



Applications of galvanized gabion


Galvanized gabion can be used in various applications, here are the following applications:

Retaining wall.
Channel lining.
Bridge protection.
Dam protection.
Riverbank protection.
Slope protection.
Coastal protection.
Flood controlling.
River regulation
Fireplace.
Landscape construction.
Gabion planter.



Retaining Wall Hexagonal Gabion Box For Channel Lining And Coastal Protection 0
