Stainless Expanded 15w2 Steel Bar Grating Power Coating

Stainless Expanded 15w2 Steel Bar Grating Power Coating
Stainless Expanded 15w2 Steel Bar Grating Power Coating

Large Image :  Stainless Expanded 15w2 Steel Bar Grating Power Coating

Product Details:
Place of Origin: CHINA
Brand Name: NOVA
Payment & Shipping Terms:
Minimum Order Quantity: 10 Piece/Pieces
Price: $9.90 - $80.00/ Piece
Packaging Details: normally packed in pilling up ways with two pieces of square wood on both upperand bottom sides. there are four or six pieces of M10 long bolt penetrading
Delivery Time: Quantity(Tons) 1 - 1200 >1200 Est. Time(days) 30 To be negotiated
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000 Piece/Piecess per Month
Detailed Product Description
Material: Lower Carbon Steel Steel Grating Size: 3'x20', 3'x24', 3'x30'
Steel Bearing: 30,40,60,100mm Surface Treatment: Mild, Galvanized,power Coating
Application: Trench Drains,Driveway Road,Garage Trench Drain Specification: 19-w-4, 15-w-2, 30/100, 40/50
Pitch Of Bearing Bar: 15-30mm, 40mm, 60mm, 80mm, 90mm Etc. With 30, 40mm Rec Pitch Of Cross Bar: 30, 38, 50, 76, 100mm Etc. With 50, 100mm Recommended.
High Light:

expanded steel bar grating

,

expanded stainless steel bar grating

,

15w2 steel bar grating

   stainless expanded steel floor grating/bar grating galvanized grating steel/stainless steel heavy duty steel grating



1.Materials: Mild carbon steel with a variety of grades;Stainless steel 201,304,316.etc.Also customerized steel.



2.Surface Treatment: Hot DIP Galvanizing /electro galvanized



3.specification list

Specifications of steel gratings
No Item Description
1 Bearing bar 20x5, 25x3, 25x4, 25x5, 30x3, 30x4, 30x5, 32x3, 32x5, 40x5, 50… 75x8mm, etc.
2 Bearing bar pitch 25, 30, 30.16, 32.5, 34.3, 40, 50, 60, 62, 65mm, etc.
3 Cross bar 5x5, 6x6, 8x8mm (twisted bar or round bar)
4 Cross bar pitch 40, 50, 60, 65, 76, 100, 101.6, 120, 130mm or as customers' requirement.
5 Surface treatment Untreated, Hot dip galvanized, Cold dip galvanized, Painted, Powder coated, or as customers' requirement.
6 Flat bar type Plain, Serrated (tooth-like), I bar (I section)
7 Material standard Low carbon steel (CN: Q235, US: A36, UK: 43A)
8 Galvanization standard CN: GB/T13912, US: ASTM (A123), UK: BS729



Stainless Expanded 15w2 Steel Bar Grating Power Coating 0

Cross Rod Pitch load Bar Pitch load Bar Specification(Width×Thickness)
20×3 25×3 32×3 40×3 20×5 25×5
30 100 G203/30/100 G253/30/100 G323/30/100 G403/30/100 G205/30/100 G255/30/100
50 G203/30/50 G253/30/50 G323/30/50 G403/30/50 G205/30/50 G255/30/50
40 100 G203/40/100 G253/40/100 G323/40/100 G403/40/100 G205/40/100 G255/40/100
50 G203/40/50 G253/40/50 G323/40/50 G403/40/50 G205/40/50 G255/40/50
60 50 - G253/60/50 G253/60/50 G403/60/50 G205/60/50 G255/60/50
Cross Rod Pitch load Bar Pitch load Bar Specification(Width×Thickness)
32×5 40×5 45×5 50×5 55×5 60×5
30 100 G325/30/100 G405/30/100 G455/30/100 G505/30/100 G555/30/100 G605/30/100
50 G325/30/50 G405/30/50 G455/30/50 G505/30/50 G555/30/50 G605/30/50
40 100 G325/40/100 G405/40/100 G455/40/100 G505/40/100 G555/40/100 G605/40/100
50 G325/40/50 G405/40/50 G455/40/50 G505/40/50 G555/40/50 G605/40/50
60 50 G325/60/50 G405/60/50 G455/60/50 G505/60/50 G555/60/50 G605/60/50

Stainless Expanded 15w2 Steel Bar Grating Power Coating 1

Application

Steel grating used in flooring, catwalk, mezzanines/decking, stair tread, fencing, ramp, dock, trench cover, drainage pit cover, maintenance platform, pedestrian/crowded pedestrian, factory, workshop, motor rooms, trolley channel, heavy loading area, boiler equipment and heavy equipment area, office buildings, apartments, train stations, department stores, hospitals,amusement parks,etc.

Stainless Expanded 15w2 Steel Bar Grating Power Coating 2

Packing: normally packed in pilling up ways with two pieces of square wood on both upperand bottom sides. there are four or six pieces of M10 long bolt penetrading the gratings and screwing together. it is suitable for loading and unloading by fork-lift and crane.

Stainless Expanded 15w2 Steel Bar Grating Power Coating 3

Q: Why to choose us? Any advantages?

A: The answer is Yes.

1) The most preferential price:Our offer will be reasonable, our price will be cheaper in the

same quality.

2) Customize: We can make the product as your request, specification,size and quality can meet

your request.

3) Mix order: We accept mix order, different specification and small quantity order.

4) Quality assurance:We have professional quality testing team.They will test the products before shipment.

5) After-sales service:Any question is welcome.

Q: Can I order one piece for sample to test the quality?
A: Yes, We recommend to check the sample before order.
