Product Details:
Payment & Shipping Terms:
|
Material: | Galvanized Wire | Wire Diameter: | 2.0-4.0mm |
---|---|---|---|
Mesh Size: | 60*80,80*100,100*120,120*150mm Etc | Hole Shape: | Hexagonal |
Surface Treatment: | Zinc Coated | Size: | 1*1*0.5,1*1*1,2*1*1,3*1*1m Etc. |
Highlight: | welded gabion box,garden wall wire baskets |
Hot-dipped galvanized hexagonal gabion box / gabion basket / gabion stone cage
Product Description:
Galvanisation is the process of applying a protective zinc coating to steel, to prevent rusting. The most common method is hot-dip galvanizing, It forms a coating of corrosion-resistant zinc which prevents corrosive substances from reaching the more delicate part of the metal.
As it's good performance is due to its inherent corrosion control, high resistance, no commercial coating for protecting steel has proven to be more serviceable and of such predictable performance atmosphere than hot dip galvanizing.
Gabion wire mesh boxes/mattress specifications
Wire diameter/mm | Mesh size /mm | Size/m | No. of diaphragms | Deviation |
2.0-4.0 |
60*80 80*100 90*110 100*120 120*150 |
1*1*0.3 | 0 | ± 5% |
1*1*0.5 | 0 | |||
1*1*1 | 0 | |||
2*1*0.3 | 1 | |||
2*1*0.5 | 1 | |||
2*1*1 | 1 | |||
3*1*0.3 | 2 | |||
3*1*0.5 | 2 | |||
3*1*1 | 2 | |||
4*1*0.3 | 3 | |||
4*1*0.5 | 3 | |||
4*1*1 | 3 | |||
2*0.5*0.5 | 1 | |||
3*0.5*0.5 | 2 | |||
Customized according to buyer's requirement. |
Advantages:
1. Metal Gabion made of hexagonal double twisted wire mesh provide adequate strength to the structure to withstand forces generated by retained earth and flowing water.
2. The flexibility of the double twisted hexagonal mesh helps in withstanding differential settlement without fracturing the structure particularly when a structure is installed on unstable and uneven ground or in an area where scours from waves or current can undermine etc.
3. The permeable nature of the Metal Gabion eliminates buildup of hydrostatic pressure behind the retaining structure and uplifts caused by turbulent flows. Hence the thickness of the required structure is significantly reduced.
4. Metal Gabion structures are heavy monolithic gravity units able to withstand earth's thrust. Its efficiency increases instead of decreasing with age since further consolidation takes place as silt and soil collect on the voids and vegetation establishes itself.
Gabion application:
Wire mesh gabion baskets filled with stone and used for various applications including: retaining walls, mechanically stabilized soil retaining structures, stream,bank protection, slope paving, outfall structures, weirs, etc
Packing & Delivery:
Packing Details: In pallet or in bundle, as buyer's requirement.
Delivery Details: 5-10 Days after received the deposit by TT, according to buyer's quantity.
