Slope Protection Gabion Mattress , Landscape Rock Cages Nova-088

for slope protection / pvc coated gabion river mattress

Product Description:

, also called gabion mattress, revet mattress, is a type of container with hexagonal meshes and double or triple twisted structure. The revet mattress has relatively smaller height compared with gabion box. The gabion mattress is widely used in the riverbank protection, coastal protection and channel linings.

can be made of different materials, according to different material, the can be divided into different styles.

Galvanized steel wire before fabrication. Using the galvanized steel wire for fabricating the , which has excellent corrosion and rust resistance performance during using. But the zinc coating on the joints of gabions may slightly falling off during fabrication.

PVC coated .

PVC coated wire before fabrication. Cover the steel wire with PVC film, which can be green, gray and various other colors and then fabricate the gabion as usual. The PVC coated material can not only supply excellent corrosion and rust resistance, it can also make the revet mattress colorful and beautiful. The PVC coated wire is just suitable for woven only.

Sizes of River mattress/:

How to built gabions?

Step 1
Open the bundle and unfold each unit.

Step 2
Lift the sides, the ends and the diaphragms of each unit into vertical position.

Step 3
Attach the sides of four corners together with locking wire fastener or lacing wire and the diaphragms to the front and back of the gabion.

Surface treatment of gabion mattress: The woven steel wire used to manufacture the mattress is heavy zinc coated steel wire or pvc coated wire.

Features of

Flexible, It can be made into different length, width and height to suit different applications.

Eco-friendly, The will not limit the growth of plant, the growing plant can make the gabion blend with surrounding environments.

Corrosion and rust resistance,Galvanized steel wire, PVC coating steel wire and zinc-aluminum alloy wire all can supply excellent corrosion and rust resistance performance for durable and longer service life.

High tensile strength, The are made of high quality steel wire, which is high tensile strength to resist the high impact from tidewater, flood.

Applications:

can be fabricated in different technologies, which is woven or welded into different mesh types and specs.

Welded . The main application of welded is for decoration, such as landscape construction, fire place and planters applications. It can be used for slope protection as the woven .

Woven . The woven is a functional product, which is widely used for slope protection, coastal protection, river bank protection, channel lining, revetment and other protective applications.

When requesting a quote, please specify:

size of units (LxWxH)
type of mesh size (60*80,80*100mm)
type of coating (galvanized wire, galfan wire,pvc coated wire)
Wire diameter(2mm,3mm)
