Flood Control Bastion Barrier Metal Gabion Baskets 2" × 2" / 3" × 3" / 4" × 4"

Certification
China Hebei Nova Metal Wire Mesh Products Co., Ltd. certification
China Hebei Nova Metal Wire Mesh Products Co., Ltd. certification
Hanna..you are FANTASTIC!! I am so happy that I found you.

—— Rich sr

I know I keep repeating myself but words cannot express how grateful we are for your hospitality and generosity. We look forward to doing business with you and helping you build and promote your company and it's capabilities. We are both very excited about the future

—— Craig

I'm Online Chat Now

Flood Control Bastion Barrier Metal Gabion Baskets 2" × 2" / 3" × 3" / 4" × 4"

Flood Control Bastion Barrier Metal Gabion Baskets 2" × 2" / 3" × 3" / 4" × 4"
Flood Control Bastion Barrier Metal Gabion Baskets 2" × 2" / 3" × 3" / 4" × 4" Flood Control Bastion Barrier Metal Gabion Baskets 2" × 2" / 3" × 3" / 4" × 4"

Large Image :  Flood Control Bastion Barrier Metal Gabion Baskets 2" × 2" / 3" × 3" / 4" × 4"

Product Details:
Place of Origin: China
Brand Name: Nova
Certification: ISO9001
Model Number: Nova-091
Payment & Shipping Terms:
Minimum Order Quantity: 50 sets
Price: Negotiable
Packaging Details: Covered with plastic and then put on wooden pallet
Delivery Time: 10-15 days, or according to buyer's requirement
Payment Terms: T/T, Western Union
Supply Ability: 1000 sets per week
Detailed Product Description
Mesh Opening: 2" × 2", 3" × 3", 4" × 4" Color: Grey,green,beige,black Etc
Wire Diameter: 2.0-5.0mm Hole Shape: Square
Type: Welded Mesh Applications: Bastion Barrier
High Light:

gabion rock wall cages

,

galvanised steel stone cage

Welded mesh gabions for bastion barrier / flood control bastion barrier



Product Description:



Bastion barrier is a solid and high strength structure, which is widely used in the military defense and flood controlling applications. It can protect troops and civilian personnel from attacks and intruders, it can defend the bullet and gunfire out of the base.



The structure of bastion barrier is similar as the welded gabion, which is connected by the spiral wires. The filling material of bastion barrier is commonly sands. The welded gabions are lined with heavy duty non-woven polypropylene geotexitile to prevent filling materials from leaking out from the large opening.



Bastion barrier has standard and recoverable types according to different structure. As we all know, though the installation of bastion barrier is easy and fast, but when it is filling with sands or stones, the uninstallation may cost several time and efforts.besides, the war is tight, it they are leaved there, it may destroy the environment, so we have developed a new type of products, named as recoverable bastion barrier. Just removing one joint pin and the filling materials flowing out from the bastion barrier unit. In this way, the bastion barrier can be recovered in a simple, fast way. Additional, the bastion barrier can be folded and take another military base to save cost and protect the environments.



Item Height Width Length cells
01 2' 2' 4' 2
02 2' 2' 10' 5
03 3'3" 2'6" 30' 9
04 3'3" 3'3" 32'9" 10
05 3'3" 5' 32'9" 6
06 4 1' 4' 2
07 4'6" 3'6" 32'9" 9
08 4'6" 4' 32'9" 9
09 5'6" 2' 10' 5
10 7' 3'6" 108' 30
11 7'3" 5' 100' 20
12 7'3" 7' 91' 15
13 9' 3'6" 10'5" 6



Material: electric galvanized, hot dipped galvanized or Galfan coated steel wire.
Wire diameter: 3 mm - 5 mm.
Mesh opening: 2" × 2", 3" × 3", 4" × 4".
Geotextile color: white, gray, green, sand and other colors.
