Flexible PVC Coated Gabion Box / Wire Mesh Gabion Basket For Road Protection

Flexible PVC Coated Gabion Box / Wire Mesh Gabion Basket For Road Protection
Flexible PVC Coated Gabion Box / Wire Mesh Gabion Basket For Road Protection Flexible PVC Coated Gabion Box / Wire Mesh Gabion Basket For Road Protection

Large Image :  Flexible PVC Coated Gabion Box / Wire Mesh Gabion Basket For Road Protection

Product Details:
Place of Origin: China
Brand Name: Nova
Certification: ISO9001
Model Number: Nova-145
Payment & Shipping Terms:
Minimum Order Quantity: 200 sets
Price: Negotiable
Packaging Details: Covered with plastic and the put on wooden pallet
Delivery Time: 5-10 days, according to buyer's requirement
Payment Terms: T/T, Western Union
Supply Ability: 10000 sets per week
Detailed Product Description
Wire Diameter: 2.0-4.0mm Hole Size: 60*80,80*100,100*120 Etc
Hole Shape: Hexagonal Type: Double Twist Woven Mesh
Sample: Free Feature: Easy Transport
Surface Treatment: PVC Or PE Coated Application: Road Protection Mesh
High Light:

plastic coated wire mesh baskets

,

pvc coated gabion box

Flexible PVC coated gabion box / Gabion box for road protection



PVC coated gabion description:



Gabion basket also named gabion box, is weaved by corrosion resistance, high strength and good ductility galvanized wire or PVC coating wire through mechanical. the material is zinc-5% aluminum alloy (galfan) wire, low carbon steel wire, stainless steel or iron wire. Gabion mattress is similar to gabion basket. But gabion mattress's height is lower than gabion basket, structure is flat and big. Gabion basket and gabion mattress are stone containers, uniformly partitioned into internal cells, interconnected with other containers and filled with stone at site to form flexible, permeable, monolithic structures to control and guide water or flood, protect dam or seawall, or used as retaining walls, channel lining and other applications.



PVC coating will increase the protection ability in high polluted environment, this gabion can fuse with surroundings through choosing different color.





PVC coated gabion mesh box & mattress



Wire diameter/mm Mesh size /mm Size/m No. of diaphragms Deviation
2.0-5.0

60*80

80*100

90*110

100*120

120*150

1*1*0.3 0 ± 5%
1*1*0.5 0
1*1*1 0
2*1*0.3 1
2*1*0.5 1
2*1*1 1
3*1*0.3 2
3*1*0.5 2
3*1*1 2
4*1*0.3 3
4*1*0.5 3
4*1*1 3
2*0.5*0.5 1
3*0.5*0.5 2
Customized according to buyer's requirement.



Features of gabion



Convenient to transport and install.
Gabion basket or mattress are formed to a flexible, permeable and monolithic structure. Soft structure can adapt the change, will not be damaged, has better safety and stability than rigid structure.
Due to the spacing among stones, it has good ability of resistant to scour, silt can be left in the spacing where plant can grow.
Low cost, long life.



Applications of gabion


Control and guide water or flood.
Retaining walls.
Channel lining.
Dam and seawall protection of scour resistance.
Bridge and pier protection of scour resistance.
Reservoir and river closure cages.
Protect land from erosion.
For Villa Landscape.



Flexible PVC Coated Gabion Box / Wire Mesh Gabion Basket For Road Protection 0
