Walkway / Platform Steps Metal Serrated Bar Grating

Walkway / Platform Steps Metal Serrated Bar Grating
Walkway / Platform Steps Metal Serrated Bar Grating

Large Image :  Walkway / Platform Steps Metal Serrated Bar Grating

Product Details:
Place of Origin: CHINA
Brand Name: NOVA
Payment & Shipping Terms:
Minimum Order Quantity: 5 Ton/Tons
Price: 1-50US$/m2
Packaging Details: 1. Bandage and Paperboard: Generally applies to neat steel plate; 2. Screw Locking Method: Use 4 screw rods through the aperture of the steel grid, for high strength; 3. Steel Pallet: Traditional export packing.
Delivery Time: Quantity(Tons) 1 - 1200 >1200 Est. Time(days) 30 To be negotiated
Payment Terms: L/C, T/T, Western Union
Supply Ability: 60 Ton/Tons per Week
Contact Now

Walkway / Platform Steps Metal Serrated Bar Grating

Description
Material: Carbon Steel, Aluminum Steel, Stainless Steel Steel Grating Size: 3'x20', 3'x24', 3'x30'
Steel Bearing: 30,40,60,100mm Surface Treatment: D, Galvanized,power Coating
Application: Trench Drains,Driveway Road,Garage Trench Drain Specification: 19-w-4, 15-w-2, 30/100, 40/50
Pitch Of Bearing Bar: 15-30mm, 40mm, 60mm, 80mm, 90mm Etc. With 30, 40mm Rec Pitch Of Cross Bar: 30, 38, 50, 76, 100mm Etc. With 50, 100mm Recommended.
Bearing Bar Type: Flat Bar Type, Serrated Bar Type, I-Bar Type Anchoring Devices: Saddle Clips, Countersunk Lands, Weld Lugs, "G" Clips, "J" Clips
Highlight:

walkway serrated bar grating

,

platform steps serrated bar grating

,

metal serrated bar grating

    galvanized steel grating/hot dipped galvanized steel grating prices steel grating walkway / platform grating steps​





Steel bar grating is a good choice for strength, safety, long-term cost and durability. Bar Grating consists of a series of bearing bars, welded (or otherwise joined) at various intervals to perpendicular cross bars to form a load-bearing panel. It is available in a wide selection of panel sizes; bar sizes, and material types.

Stair treads are the horizontal sections of stairs that serve as the step surface of each step.

Walkway / Platform Steps Metal Serrated Bar Grating 0

Material Standard
ASTM A36, A1011, A569, Q235, S275JR, Stainless steel 304/316,
d steel & Low carbon steel, etc
Bearing Bar
(Width x Thickness)
25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10…..100 x10mm etc;
I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc
US standard: 1''x3/16'', 1 1/4''x3/16'', 1 1/2''x3/16'', 1''x1/4'',1 1/4''x1/4'', 1 1/2''x1/4'', 1''x1/8'', 1 1/4''x1/8'', 1
1/2''x1/8'' etc
Bearing Bar Pitch
12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3,32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc.
US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
Twisted Cross Bar Pitch
38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2'' & 4'' etc
Surface Treatment
Untreated(black), Hot-dipped galvanized, Powder coated, Electroplate, Painting or as per customers' requirement.

Walkway / Platform Steps Metal Serrated Bar Grating 1

Welded Steel Grating
Welded steel bar grating is the most popular type, due to its combination of strength, ease of installation and cost-effectiveness. See Welding Standards for more information. Applications include platforms, ventilation grates, stair treads and safety covers. The selection of welded grating products available include standard weld, close-mesh, railroad and heavy-duty
Press-Locked Grating
ress-locked grating features a system of perpendicular interlocking bars that provide a smooth, clean look. This makes it perfect for architectural applications where aesthetic sensibilities are of utmost importance. Press-locked grating can be produced from carbon steel, stainless steel or aluminum. Its surface can be treated by galvanizing, painting or powder coating
Heavy-Duty Grating
Heavy-duty bar grating provides maximum strength in order to accommodate heavier loads in industrial and commercial settings. Heavy-duty bar grating also has a long lifespan which makes it ideal for demanding tasks over a long period of time.
Bar Grating Stair Treads
These stair treads are available in many different materials. All bar grating stair treads offer the unbeatable combination of superior strength, affordability and ease-of-installation

Applications
Steel grating is widely used for work platforms. Catwalks, transportation
servicing areas and vehicle steps.

Walkway / Platform Steps Metal Serrated Bar Grating 2

Grating Standard Packing Method:
1. Bandage and Paperboard: Generally applies to neat steel plate;
2. Screw Locking Method: Use 4 screw rods through the aperture of the steel grid, for high strength;
3. Steel Pallet: Traditional export packing.

4. According to customer's packing requirements.Walkway / Platform Steps Metal Serrated Bar Grating 3

1.Q: Where is your factory?
A: You are welcomed to visit our factory. Our factory locates in hengshui City,Hebei province. The nearst airport is ZhengDing Airport at ShiJiazhuang And it is 2 hours away from Anping, 3 hours away from Beijing.



2Q: Samples?
A: Sample is available for you.

Usually the customer need to pay the freight, We'll send back the courier charge if you make an order.

3. Q: Price?

We are professional manufacturer with more than 20 years production experice,we promise our price is very competitive.



4. Delivery time?



Usually within 10-15 days ,
