Product Description:
Gabion Wire Mesh is a type of wire mesh made of high quality low carbon steel wire, which is mainly used for gabion cages, gabion basket mesh and gabion wall mesh. It is a versatile and durable product that is widely used in various construction projects.
Product Overview
The Gabion Wire Mesh comes in various sizes and colors to meet the specific needs and preferences of our customers. It is available in the following specifications:
- Length: 1m-6m
- Packing: In Bundles
- Colors: Green, Blue, Grey, etc.
- Surface Treatment: Galvanized, PVC Coated
- Mesh Size: 60x80mm, 80x100mm, 80x120mm, 100x120mm, 100x150mm
Typical Gabion Sizes
| Length,m |
Width, m |
Height, m |
Number of Cells, each |
Volume, m3 |
| 2 |
1 |
1 |
2 |
2 |
| 3 |
1 |
1 |
3 |
3 |
| 4 |
1 |
1 |
4 |
4 |
| 2 |
1 |
0.5 |
2 |
1 |
| 3 |
1 |
0.5 |
3 |
1.5 |
| 4 |
1 |
0.5 |
4 |
2 |
| 2 |
1 |
0.3 |
2 |
0.6 |
| 3 |
1 |
0.3 |
3 |
0.9 |
| 4 |
1 |
0.3 |
4 |
1.2 |
Gabion Wire Mesh is commonly used to create gabion cages, which are wire mesh containers filled with stones or other materials.
These cages are used for various purposes such as erosion control, retaining walls, and landscaping. Gabion Wire Mesh is also used to create gabion baskets, which are wire mesh boxes filled with stones or other materials. These baskets are used for riverbank protection, slope stabilization, and other civil engineering projects. Gabion Wire Mesh is an ideal material for building gabion walls, which are wire mesh structures filled with stones or other materials. These walls are used for sound barriers, decorative walls, and flood control.
Another important application of Gabion Wire Mesh is for water and soil protection. The mesh can be used to create retaining walls, channels, and embankments to prevent erosion and control the flow of water. This is especially useful in coastal areas where erosion is a major concern.
Lastly, Gabion Wire Mesh is commonly used in protection engineering of seaside areas. The mesh can be used to create breakwaters, seawalls, and other structures to protect coastlines from erosion and wave impact. Its strength and durability make it an ideal choice for withstanding harsh marine environments.
In conclusion, Gabion Wire Mesh is a versatile and reliable solution for various applications. With its multiple uses and excellent properties, it is a must-have product for any construction or engineering project. Choose NOVA Gabion Wire Mesh for superior quality and performance.
Features
- High quality low carbon steel wire
- Durable and long-lasting
- Versatile and multipurpose
- Available in various sizes and colors
- Easy to install and maintain
- Can be customized to meet specific requirements
Benefits
- Provides excellent erosion control
- Creates a strong and stable structure
- Allows for natural water filtration
- Enhances the aesthetic appeal of the surrounding area
- Cost-effective solution for construction projects
Conclusion
Gabion Wire Mesh is a versatile and durable product that offers a wide range of applications in construction projects. With its high quality and customizable features, it is the ideal choice for gabion cages, gabion basket mesh, and gabion wall mesh. Whether you need erosion control, slope stabilization, or flood control, Gabion Wire Mesh is the perfect solution for all your needs.
Technical Parameters:
| Product Name |
Gabion Wire Mesh |
| Other Names |
Gabion Caged Wire Mesh, Gabion Basket Mesh, Gabion Caged Wire Mesh Box |
| Packing |
In Bundles |
| Tensile Strength |
380-550N/mm2 |
| Wire Diameter |
2.0mm-4.0mm |
| Application |
Control And Guide Of Water Or Flood, Flood Bank Or Guide Bank, Preventing Of Rock Breaking, Water And Soil Protection, Bridge Protection, Strengthening Structure Of Soil, Protection Engineering Of Seaside Area |
| Surface Treatment |
Galvanized, PVC Coated |
| PVC Coating Color |
Green, Blue, Grey, Etc. |
| Width |
1m-2m |
| Mesh Size |
60x80mm, 80x100mm, 80x120mm, 100x120mm, 100x150mm |
| Color |
Green, Blue, Grey, Etc. |
| Length |
1m-6m |
Keywords: Gabion Basket Mesh, Gabion Mesh, Gabion Caged Wire Mesh
Packing and Shipping:
Packaging and Shipping of Gabion Wire Mesh
1. Packaging
Gabion wire mesh is usually packed in two ways: bundles or pallets.
- Bundle packaging: The wire mesh is coiled into bundles and then wrapped with plastic film. The bundles are then secured with steel straps or wire ties.
- Pallet packaging: The wire mesh is stacked on wooden or steel pallets and then wrapped with plastic film. The pallets are then secured with steel straps or wire ties.
2. Shipping
Depending on the quantity and size of the gabion wire mesh, it can be shipped by sea, air, or land.
- Sea shipping: For large quantities, the wire mesh is usually shipped by sea in containers. The containers are loaded onto cargo ships and transported to the destination port.
- Air shipping: For urgent or small orders, the wire mesh can be shipped by air. It is usually packed in cartons or wooden cases and transported by air freight.
- Land shipping: For domestic deliveries, the wire mesh can be transported by trucks or trains. It is usually packed in bundles or on pallets and secured with straps or ties.
Regardless of the shipping method, our team will ensure that the gabion wire mesh is packed securely to prevent any damage during transportation.
