2-4mm Double Twisted Hexagonal Gabion Basket 3x1x1m Galvanized Mesh For Slope Protection

Technical Specifications

Product Highlights

• Double twisted hexagonal weave never unravels even when a wire is cut
• 2-4mm wire diameter with hot dip galvanized finish for long outdoor life
• 60x80mm and 80x100mm apertures with thicker selvedge wires at edges
• Elastic structure absorbs settlement and redistributes soil loads
• Vegetation can grow through the mesh for natural slope greening
• PVC coated option available for acidic soil and marine environments

Structural Design and Performance

Each mesh panel is mechanically woven with a double twist, meaning every wire pair is twisted three half turns around the next pair. This interlock makes the weave fail-safe: a single broken wire cannot open the mesh, which is why double twisted baskets keep their integrity under rockfall impact, water flow and long term soil pressure.

Because the basket remains flexible after filling, it works as a dynamic earth reinforcement membrane. Drainage passes freely through the openings, hydrostatic pressure stays low behind the wall face, and the structure simply follows minor ground settling without cracking - a decisive advantage over rigid concrete or welded alternatives on unstable slopes.

Typical Project Applications

• Highway and railway cut slope stabilization with rockfall protection
• River bank, canal and seawall erosion control and scour defense
• Ecological hill greening and landslide restoration programs
• Foundation pit support and mountain shotcrete reinforcement
